Allbro 23-Hole Battery Busbar Box

Description

Allbro 23-Hole Battery Busbar Box

External Dimensions (mm): 160H x 560W x 95D

Bolt size: M8

No. of termination points: 23

Copper busbar size: 10H x 560W x 30D

IP Rating: IP68

The Battery Busbar Box range ticks all the boxes for electrical installations. It’s completely waterproof with an IP68 rating and strong enough to handle all kinds of weather. The box is non-conductive and flame-retardant, which makes it ideal for solar where the risk of DC arcs increases. GRP (Glass Reinforced Polyester) material is rust-free with a 25+ year UV life for long term performance.

  • Max rating 600A (calculated at 2A/mm2)
  • M8 holes drilled and taped 24mm apart

Included in the box:

  • M8 12mm stainless steel bolts
  • M8 stainless steel spring washers
  • M8 stainless steel flat washer
  • 1 x Drilling template

SKU: 060-554
